Description of Ice Cream Cone Making Machine

Description of  Ice Cream Cone Making Machine
The LG40 automatic baking machine is used for rolling sugar cones.It offer cones to the next process to be filled with ice cream.First it dispenses batter on the baking plates to prepare the waffles for shaping,then rolls them up,keep them in shape unload them finally.It is the main device of the production line.Excellent performances have allowed Intemational Standards to be comfortably met.
Specifications of  Ice Cream Cone Making Machine


Model	LG40
Capacity	2400pcs/h
Finished Product Size(22.5°)	48-52mm
	120-135mm
Power	12kw
LPG consumption	4kg/h
Compressed air pressure	0.6MPA
Compressed air consumption	6 MPa
Weight	3000kg
Outline size	3000*2000*1680mm
